47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk
47inch multimedia interactive portable touch all in one kiosk

47inch multimedia interactive portable touch all in one kiosk

Model NO.:
HBY-W470
Price:
USD 1000.00-2500.00 / piece
Delivery:
FOB
Minimum order quantity:
1 piece
Supply Ability:
10000 piece / Month
Country of Origin:
Shenzhen,HongKong
Stock Time:
within 7days after confirm order Day

47inch multimedia interactive touch all in one kiosk



1)Android system

O/S:

Android 4.4

Chipset:

RK3188 Cortex-A9 Quad-Core CPU 1.8GHz

Memory:

DDR3, 2/4/8GB

Storage

128G SSD/320G/500G SATA

OSD Language

Chinese, English etc.

Network

Wi-Fi, lan,BT,etc

Ports:

USB*2,SD*1,VGA*1,RJ45*1,Audio out*1,SIM port*1

OSD Language

Chinese, English, Spanish, Russian, German, French, Arabic, etc.

Support split screen

Any split screen display, multiple window video player, can achieve different window showing different content

Support the multimedia file
formats

MPEG1/2/3/ 4,AVI, RM, WMV, DAT, JPEG, BMP, PPT, WORD, EXCEL, TXT, MP3, RMVB, SWF etc.

Combined media display

Support video, picture, FLASH, marquee text and other combined media display.

Playback function

Support different templates scenes,multiple task packages looping

Environment

Operating Temperature :0°C to 40°C
Storage Temperature :-20°C to 60°C
Humidity:20%-80% RH at 40°C,

System Power Supply

AC 110V~240V,50/60HZ



Windows system

Processor

Intel Core Celeron 1037U,Dual Core 1.8G

GPU:

Intel HD Graphics intel® NM70 Chipset

Chipset

Intel Chipset HM65

Memory

DDR3 4GB ,Support up to 8GB

Ethernet

Realtek GBE RJ45,8111E

Audio

Realtek HD Audio,Support Line-in,Line-out,Mic-in,Spdif,Speaker

Display

VGA1,VGA2,LVDS.

Storage

128G SSD

Power Supply

DC 12V Power Supply, or ATX Power Supply

CPU_Fan

Thin Cool Fan

Size

Mini-ITX

Ports:

4*USB2.0 ,1*VGA, 1*HD-MI, 1*RJ-45, 1*DC, 1*MIC-IN, 1* LINE-OUT

Built-in I/O

1x24bit LVDS,4xUSB,5xCom,2xFan_Slot, SIM Card slot,Spdif,VGA header(12P standard)

Expansion

2xMini-PCIE , Support Wifi,3G,BT,GPS

Operating Temperature

-10℃ to 60℃

Storage Temperature

-40℃ to 80℃

Operating Humidity

0-95%

Watchdog

Option

H/W Monitoring

Monitor the state of voltage,temperature

and rotational speed of the fan

Detailed Images



TB2s_JlhFXXXXcqXpXXXXXXXXXX_!!6912453861111.jpgQQ20161103103145.pngQQ20161103103320.pngQQ20161103103347.png

Company Information

 (4)

Certifications

 QQ20161013151152

Packaging & Shipping

 QQ20160901160306



  • Place of Origin:CN;GUA
  • Brand Name:HBONY
  • Model Number:HBY-W470
  • Type:TFT
  • Application:Indoor
  • Panel Size:47 inch
  • Max Resolution:1920*1080
  • Viewing Angle:178
  • Pixel Pitch:0.4845(H)*0.4845 (V)
  • Color:16.7M
  • Contrast Ratio:3500:1
  • Brightness:450cd/m2
  • Response Time:5ms
  • Input Voltage:AC100~240V 50 /60 HZ
